Huawei S5700 Series Hardware Description

Table 3-43 Attributes of a console port
Attribute Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200 bit/s
Default value: 9600 bit/s
Mini USB port
The mini USB port is connected to a console for on-site configuration. When both the Mini
USB and console port have a cable connected, only the Mini USB port works.
Indicator Description
The S5700-52P-PWR-LI-AC has similar indicators to those on the S5700-28X-PWR-LI-AC,
except that the S5700-52P-PWR-LI-AC does not have an RPS indicator. For details, see
Indicator Description.
Power Supply Configuration
The S5700-52P-PWR-LI-AC has a built-in power module and does not support pluggable
power modules.
It can provide PoE power supply and connect to an RPS1800 power supply for power
redundancy. Table 3-44 lists its power supply configurations.
Table 3-44 Power supply configurations
Power
Supply
Configuratio
n
Available PoE
Power
Maximum Number of Ports (Fully Loaded)
No RPS used 369.6 W
l 802.3af (15.4 W per port): 24
l 802.3at (30 W per port): 12
RPS used
l V200R001:
369.6 W
l Versions later
than
V200R001:
800 W
l 802.3af (15.4 W per port): 48
l 802.3at (30 W per port): 26
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
112

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
