Attribute Description
Optical port
attributes
Depend on the optical module used
Standards
compliance
IEEE802.3ae
Working mode GE/10GE auto-sensing
Full-duplex
Console port
The console port is connected to a console for on-site configuration. The port must use a
console cable. The console port is used when a switch is powered on for the first time. For
details about the attributes of a console port, see Table 3-78.
Table 3-78 Attributes of a console port
Attribute
Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200 bit/s
Default value: 9600 bit/s
Mini USB port
The mini USB port is connected to a console for on-site configuration. When both the Mini
USB and console port have a cable connected, only the Mini USB port works.
Indicator Description
NOTE
In V200R007 and later versions, you can hold down the mode switch button for 6s and release it to start
the web initial login mode. Either of the following situations will occur:
l If the switch has no configuration file, the system attempts to enter the web initial login mode. In
this mode, the status of mode indicators is as follows:
l If the system enters the web initial login mode successfully, all mode indicators turn green
and stay on for a maximum of 10 minutes.
l If the system fails to enter the initial login mode, all mode indicators fast blink for 10
seconds and then restore to the default status.
l If the switch has a configuration file, the system cannot enter the web initial login mode. In this
case, all mode indicators fast blink for 10s, and then return to the default states.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
150
