Huawei S5700 Series Hardware Description

A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s, and must use network cables. Table 3-58 describes the attributes of a
10/100/1000BASE-T Ethernet electrical port.
Table 3-58 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
Full-duplex
Maximum
transmission
distance
100 m
1000BASE-X port
When a 1000BASE-X port uses a GE optical module, it can only transmit and receive data at
1000 Mbit/s and does not support the 100 Mbit/s transmission speed. When a 1000BASE-X
port uses a GE copper module, it can transmit and receive data at 10 Mbit/s, 100 Mbit/s, or
1000 Mbit/s. Table 3-59 describes the attributes of a 1000BASE-X Ethernet optical port.
Table 3-59 Attributes of a 1000BASE-X Ethernet optical port
Attribute
Description
Connector type LC/PC
Optical port
attributes
Depend on the module used
Standards
compliance
IEEE802.3z
Working mode Full-duplex
Combo port
A combo port refers to a pair of ports consisting of an optical Ethernet port and an electrical
Ethernet port on the panel. Each combo port matches only one internal forwarding port. A
combo port can be configured as an electrical port or an optical port, but only one port can be
active at a time. When one port is active, the other port is shut down.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
128

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
