3 Four 10GE SFP+ ports
Applicable modules and cables:
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
l GE copper module
l 10GE SFP+ optical module
l 10GE-CWDM optical module
(applicable in V200R005C00 and
later versions)
l 1 m, 3 m, and 10 m SFP+ high-
speed copper cables
l 5 m SFP+ high-speed copper cable
(applicable in V200R009C00 and
later versions)
l 3 m and 10 m AOC cables
4 One mini USB port
5 One console port 6 One USB port
7 Ground screw
NOTE
It is used with a ground cable.
8 DC power terminal
NOTE
It is used together with a DC Power Cable.
9 RPS socket
NOTE
It is used with an RPS cable, which is not
hot swappable.
- -
Port Description
100/1000BASE-X port
A 100/1000BASE-X port can send and receive data at 100 Mbit/s or 1000 Mbit/s. Table 3-92
describes the attributes of a 100/1000BASE-X port.
Table 3-92 Attributes of a 100/1000BASE-X port
Attribute
Description
Connector type LC/PC
Optical interface
attributes
Depend on the optical module used
Standards
compliance
IEEE802.3z
Working mode 100/1000 Mbit/s auto-sensing
Full-duplex
