Huawei S5700 Series Hardware Description

The mini USB port is connected to a console for on-site configuration. When both the Mini
USB and console port have a cable connected, only the Mini USB port works.
USB port
The USB port can have a USB flash drive connected to upgrade the switch, or transfer
configuration files or other files. The USB flash drive used on a switch must comply with
USB 1.1 and support the Linux operating system. Table 3-101 lists the USB flash drives
applicable to a switch.
Table 3-101 USB flash drives applicable to a switch
Capaci
ty
Vendor Model Remarks
4 GB Netac U208 You can buy Netac USB 4 GB flash drives
from Huawei or other vendors.
SanDisk Cruzer Blade Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
Hewlett-
Packard
v218G Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
PNY M1 Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
8 GB Netac U208 Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
Hewlett-
Packard
v225w Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
STEC SLUFD8GU2T
UI
Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
NOTE
Huawei is not responsible for maintenance service of USB flash drives purchased from other vendors.
Indicator Description
The S5701-28X-LI-AC has the same types of indicators as the S5700-28X-LI-AC. For
details, see Indicator Description.
Power Supply Configuration
The S5701-28X-LI-AC has a built-in power module and does not support pluggable power
modules. It can connect to an RPS1800 power supply for power redundancy.
Figure 3-38 shows the power supply mode of a built-in AC power module. The built-in AC
power module (PWR) receives power from an external power source and provides a 12 V
output to the chassis.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
179

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
