Huawei S5700 Series Hardware Description

3 Four 10GE SFP+ ports
Applicable modules and cables:
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
l GE copper module
l 10GE SFP+ optical module
l 10GE-CWDM optical module
(applicable in V200R005C00 and
later versions)
l 1 m, 3 m, and 10 m SFP+ high-
speed copper cables
l 5 m SFP+ high-speed copper cable
(applicable in V200R009C00 and
later versions)
l 3 m and 10 m AOC cables
4 One mini USB port
5 One console port 6 One USB port
7 AC socket
NOTE
It is used with an AC power cable.
8 Jack for AC terminal locking latch
NOTE
The AC terminal locking latch is not
delivered with the switch.
9 Ground screw
NOTE
It is used with a ground cable.
10 RPS socket
NOTE
It is used with an RPS cable, which is not
hot swappable.
Port Description
100/1000BASE-X port
A 100/1000BASE-X port can send and receive data at 100 Mbit/s or 1000 Mbit/s. Table
3-104 describes the attributes of a 100/1000BASE-X port.
Table 3-104 Attributes of a 100/1000BASE-X port
Attribute
Description
Connector type LC/PC
Optical interface
attributes
Depend on the optical module used
Standards
compliance
IEEE802.3z
Working mode 100/1000 Mbit/s auto-sensing
Full-duplex
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
183

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
