Huawei S6700 Series

Model Center
Wavelengt
h (nm)
Transmi
t Power
(dBm)
Receiver
Sensitivi
ty (dBm)
Overloa
d
Optical
Power
(dBm)
Extincti
on
Ratio
(dB)
SFP-GE-ZBXU1
(Single-fiber single-fiber
bidirectional optical
module)
RX1570/
TX1490
-2.0 to
+4.0
≤ -26
-3.0
≥ 9
GE-CWDM Optical Module
Table 7-4 lists the attributes of GE coarse wavelength division multiplexing (CWDM) optical
modules.
Table 7-4 Attributes of CWDM optical modules
Center
Waveleng
th (nm),
Model
1471, CWDM-
SFPGE-1471
1491, CWDM-
SFPGE-1491
1511, CWDM-
SFPGE-1511
1531, CWDM-
SFPGE-1531
1551, CWDM-
SFPGE-1551
1571, CWDM-
SFPGE-1571
1591, CWDM-
SFPGE-1591
1611, CWDM-
SFPGE-1611
Specificati
ons
Encapsulation type: eSFP
Transmission distance: ≤ 80 km
Fiber type: single-mode, LC
Standard: CWDM
Operating temperature: 0°C to 70°C
l Transmit power: 0 dBm to 5.0 dBm
l Receiver sensitivity: ≤ -28.0 dBm
l Overload optical power: -9.0 dBm
l Extinction ratio: ≥ 8.5 dB
NOTE
The appearance of CWDM optical modules is similar to that of common optical modules. These optical
modules are distinguished by their labels. In practice, the corresponding optical fibers are labeled to
distinguish the optical modules.
GE-DWDM Optical Module
Table 7-5 lists the attributes of GE dense wavelength division multiplexing (DWDM) optical
modules.
