Huawei S6700 Series

No. Indicator Color Description
2 PWR2: power
module indicator
- Off: No power module is available in
power module slot 2, or the switch has only
one power module but the power module
does not work normally.
Green Steady on: A power module is installed in
power module slot 2 and is working
normally.
Yellow Steady on: The switch has two power
modules installed. Any of the following
situations occurs in power module slot 2:
l A power module is available in this slot
but its power switch is in OFF position.
l A power module is available in this slot
but it is not connected to a power
source.
l The power module in this slot has
failed.
3
SYS: system
status indicator
- Off: The system is not running.
Green
l Fast blinking: The system is starting.
l Slow blinking: The system is running
normally.
Red Steady on: The system does not work
normally after registration, or a fan alarm
or temperature alarm has been generated.
4 STAT: status
indicator
Green
l Off: The status mode is not selected.
l Steady on: The status mode (default
mode) is selected, and service port
indicators show the link connection
states and link activity on ports.
5 SPED: speed
indicator
Green
l Off: The speed mode is not selected.
l Steady on: The speed mode is selected.
In this mode, service port indicators
show port speeds. After 45 seconds, the
service port indicators automatically
restore to the status mode.
