Huawei S6700 Series

Mode Color Description
Stack Green and
yellow
l Off: Port indicators do not show the
stack member ID of the switch.
l Both steady on:
The switch is not the master switch in
a stack.
– If the indicators of a service port are
steady on, the number of the service
port is the stack ID of the switch.
– If indicators of the first nine ports
are steady on, the stack ID of the
switch is 0.
l Green indicator steady on and yellow
indicator blinking:
The switch is the master switch in a
stack.
– If the indicators of a service port are
blinking, the number of the service
port is the stack ID of the switch.
– If indicators of the first nine ports
are blinking, the stack ID of the
switch is 0.
Table 2-16 Description of 40GE service port indicators in different modes (one indicator for
each port)
Display Mode Color Description
Status Green
l Off: The port is not connected or has
been shut down.
l Steady on: A link has been established
on the port.
l Blinking: The port is sending or
receiving data.
Speed Green
l Off: The port is not connected or has
been shut down.
l Steady on: The port is operating at 10
Gbit/s.
l Blinking: The port is operating at 40
Gbit/s.
