1. Captive screw 2. Airflow flag (air out) 3. Indicator 4. Fan air vent
5. Handle 6. DC power socket
- -
Table 3-3 describes the indicator on the 350 W DC power module panel.
Table 3-3 Description of the indicator on the 350 W DC power module panel
Indicator Color Description
STATUS:
running status
indicator
Green
l Off: The power input is abnormal (for example, no
input, overvoltage, or undervoltage) or the power
output is abnormal (for example, overvoltage,
overcurrent, short-circuit, or overtemperature).
l Steady on: The power module is working normally.
Specifications
Table 3-4 describes technical specifications of a 350 W DC power module.
Table 3-4 Specifications of a 350 W DC power module
Item Description
Dimensions (W
x D x H)
100 mm x 205 mm x 40 mm
Weight 0.72 kg
Rated input
voltage range
-48 V DC to -60 V DC
Maximum input
voltage
-38.4 V DC to -72 V DC
Maximum input
current
11 A
Maximum
output current
29.17 A
Rated output
voltage
12 V
Rated output
power
350 W
Part number 02310PQN
