Huawei S6700 Series

1. Captive screw 2. Airflow flag (air out) 3. Indicator 4. Fan air vent
5. Handle 6. Power switch 7. AC power socket 8. AC terminal locking latch
Table 3-11 describes the indicator on the 600 W AC power module panel.
Table 3-11 Description of the indicator on the 600 W AC power module panel
Indicator Color Description
STATUS:
running status
indicator
Green
l Off: The power input is abnormal (for example, no
input, overvoltage, or undervoltage) or the power
output is abnormal (for example, overvoltage,
overcurrent, short-circuit, or overtemperature).
l Steady on: The power module is working normally.
Specifications
Table 3-12 lists specifications of a 600 W AC power module.
Table 3-12 Specifications of a 600 W AC power module
Item Description
Dimensions (W
x D x H)
100 mm x 205 mm x 40 mm
Weight 1 kg
Rated input
voltage range
100 V AC to 240 V AC, 50/60 Hz
Maximum input
voltage
90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input
current
9 A
Maximum
output current
50 A
Rated output
voltage
12 V
Rated output
power
600 W
Part number 02310PMH
S6700 Series Ethernet Switches
Hardware Description
3 Power Modules
