Huawei S6700 Series

Indicator Color Description
Green Steady on: The AC output power is in the normal range.
Red Steady on: The power output is out of range.
l Abnormal power fan operation
l Output overvoltage
l Output overcurrent
l Short circuit
l Overtemperature
Specifications
Table 3-16 describes technical specifications of a 500 W AC power module.
Table 3-16 Technical specifications of a 500 W AC power module
Item Description
Dimensions (W x D x
H)
100 mm x 205 mm x 40 mm
Weight 1.06 kg
Rated input voltage
range
100 V AC to 240 V AC, 50/60 Hz
Maximum input
voltage range
90 V AC to 264 V AC, 47 Hz to 63 Hz
Maximum input
current
7 A to 3.5 A
Maximum output
current
l +12 V: 10 A
l -53.5 V: 7.11 A
Maximum output
power
l +12 V: 120 W
l -53.5 V: 380 W
Part number 02130879
