Huawei S6700 Series

1. Captive screw 2. Fan module indicator 3. Handle 4. Two fans
NOTE
Air is exhausted from air vents on the
panel.
Table 4-2 shows indicators on the CX7E1FANA fan module panel.
Table 4-2 Description of indicators on the CX7E1FANA fan module panel
Indicator Color Description
STATUS Off The fan module is not running.
Green
l Slow blinking: The fan module is working properly
and its communication is normal.
l Fast blinking: The fan module is working properly
but its communication is abnormal.
Red
l Steady on: The fan module has a hardware fault
and needs to be replaced.
l Slow blinking: An alarm has been generated and
needs to be handled. Common causes of this alarm
include errors of dual in-line package (DIP)
switches, short-circuit, fan blades blocked, and
other fan module faults.
Specifications
Table 4-3 describes technical specifications of a CX7E1FANA fan module.
Table 4-3 Technical specifications of a CX7E1FANA fan module
Item Description
Dimensions (W x D x H) 103 mm x 99.2 mm x 39.6 mm
Weight 250±20 g
Maximum power
consumption
12 W
Maximum wind pressure 375 Pa
Maximum wind rate 40 CFM
Operating voltage range 12 V DC
Part number 02351651
S6700 Series Ethernet Switches
Hardware Description
4 Fan Modules
