Huawei S6700 Series

1. Captive screw 2. Indicator 3. Handle 4. Two fans 5. Airflow flag (air out)
Table 4-5 describes the indicator on the FAN-060B-B fan module panel.
Table 4-5 Description of the indicator on the FAN-060B-B fan module panel
Indicator Color Meaning
STATUS:
running status
indicator
Off The fan module is not running.
Green Slow blinking: Fans are working properly.
Red Steady on: The fan module has a hardware fault and
must be replaced.
Specifications
Table 4-6 describes technical specifications of a FAN-060B-B fan module.
Table 4-6 Technical specifications of a FAN-060B-B fan module
Item Description
Dimension
s (W x D x
H)
100 mm x 220 mm x 40 mm
Number of
fans
2
Weight 0.4 kg
Maximum
power
consumpti
on
32.6 W
Maximum
fan speed
19000±10% rounds per minute (RPM)
Maximum
wind rate
64 cubic feet per minute (CFM)
Part
number
02350DNQ
