Huawei S6700 Series

Model Length Bend Radius Connector
Type
Operating
Temperature
SFP-10G-
AOC10M
10 m 30 mm
Fiber Jumper
A fiber jumper consists of a length of a single fiber or multiple fibers with optical connectors at
both ends. The fiber jumper is a fiber patch cable that connects an optical module to a fiber
terminal box.
Figure 6-4 shows the appearance of a single-mode LC/PC fiber jumper.
Figure 6-4 Appearance of a single-mode LC/PC fiber jumper
Figure 6-5 shows the appearance of a multimode LC/PC fiber jumper.
