Huawei S6700 Series

Figure 6-12 Appearance of a network cable
Figure 6-13 shows the structure of a network cable.
Figure 6-13 Structure of a network cable
X1
8
1
Main label
X2
Pin Assignments
Table 6-6 shows the pin assignments of a straight-through cable.
S6700 Series Ethernet Switches
Hardware Description
6 Cables
Issue 12 (2015-07-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
74
