1 Precautions
• After routing the cable, attach the label or fasten the tag to the cable 20 mm away from the
connector.
• After the label for the signal cable is attached to the signal cable, the rectangular text area of
the label must face rightwards or downwards.
• After the identification plate for the power cable is attached to the power cable, the text area of
the plate must face rightwards or upwards. Ensure that the side attached with the label faces
outwards.
ESD gloves
ESD wrist strap
Affixing labels / tags
Copyright © Huawei Technologies Co., Ltd. 2016 All rights reserved.
• This document aims to provide simple and distinctive guidelines for hardware installation.
• This document does not describe operations for the pre-delivery installation of the internal
cables and so on. Instead, this document describes only the operations for on-site
installation.
Electrostatic Discharge
Before touching the device, or holding the boards and IC chips, wear the ESD gloves or the
ESD wrist strap to prevent the electrostatic discharge of the human body from damaging the
sensitive components. Ensure that the other end of the ESD wrist strap is properly grounded.
• The distance between cable ties or binding straps inside the cabinet must be within 250 mm.
(For user cable, the distance must be within 200 mm.)
• Use diagonal pliers to cut off the extra part of the cable tie to the end, and ensure that the
cable tie is neat without sharp edges to prevent hand injury.
Bundling cables
