3
3 Appearance and Structure
Control board
Unit: mm
Unit: mm
IEC
Mounting
bracket
482.6
442.0
268.7
88.1
535.0
442.0
268.7
88.1
ETSI
Mounting
bracket
Power board
Fan tray
ESD jack
Grounding
point
Cabling teeth
Service board
IEC
Mounting
bracket
ETSI
Mounting
bracket
Service Subrack (with IEC mounting bracket)
Service Subrack (with ETSI mounting bracket)
