Huawei SMU01C User Manual

SMU01C
User Manual
2 Panel and Ports
Issue 03 (2015-01-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
5
Table 2-1 Indicator description
Indicator
Color
Status
Description
Run
indicator
Green
Off
The SMU01C is faulty or has no power
supply.
Blinking at 0.5 Hz
The SMU01C is running properly and
communicating with the host normally.
Blinking at 4 Hz
The SMU01C is running properly but
communication with the host is faulty.
Major
alarm
indicator
Red
Off
No major alarm is generated.
Steady on
A major alarm is generated.
LCD
The SMU01C provides a liquid crystal display (LCD) to display power system information in
real time.
Buttons
The SMU01C provides four buttons for setting and querying parameters. Table 2-2 describes
the buttons.
Table 2-2 Button description
Button
Name
Description
▲ or ▼
Arrow key
Turns to the previous or
next menu and sets
parameter values.
Cancel
Returns to the previous
menu without saving the
settings.
Enter

Enters the main menu
from the standby screen.

Enters a submenu from
the main menu.

Changes or saves the
menu settings.
NOTE:

After a menu is displayed, the standby screen is displayed and the LCD screen becomes
dark if no button is pressed for 5 minutes.

You need to log in again if no button is pressed for 8 minutes.

The preset password is 000001.
