4
Installation Angle
2.1
2
Installation Requirements
If inverters are installed in a place with abundant vegetation, in addition to routine weeding,
harden the ground underneath the inverters using cement or gravel (recommended area: 3 m x
2.5 m).
Installation Space
2.2
The clearance at the bottom must
meet the requirements on the
bending radius of the AC output
power cable.
To Next Page
