Huawei SUN2000-20KTL-M2 Quick Guide

9
•
If your Smart Dongle is not equipped with a SIM card, prepare a standard SIM card (size: 25
mm x 15 mm) with the capacity greater than or equal to 64 KB.
• Install the SIM card in the arrow direction.
• When reinstalling the cover of the Smart Dongle, ensure that the buckle springs back in
place (you can hear a click).
4G Smart Dongle (4G Communication)
•
For details about how to operate the WLAN-FE Smart Dongle SDongleA-05, see SDongleA-05
Quick Guide (WLAN-FE) .
•
For details about how to operate the 4G Smart Dongle SDongleA-03, see SDongleA-03 Quick
Guide (4G) .
•
The quick guide is delivered with the Smart Dongle. You can download them by scanning the
QR code below.
WLAN-FE 4G

Huawei SUN2000-20KTL-M2 Specifications

General

Model	SUN2000-20KTL-M2
Type	String Inverter
Max. efficiency	98.6%
European efficiency	98.3%
Max. input voltage	1100 V
Max. input current per MPPT	26 A
Number of MPPTs	2
Rated output power	20, 000 W
Start Voltage	200 V
MPPT Voltage Range	200 V - 1000 V
Max. AC Power	22, 000 VA
Output Frequency	50 Hz / 60 Hz
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Rated AC Voltage	230 V / 400 V
Max. Input Power	30, 000 W
Max. Output Power	22, 000 W
Rated Output Voltage	230 V / 400 V
