Huawei SUN2000-50KTL-ZHM3 Quick Start Guide

9
COM Port Pin Definitions
No.
Definiti
on
Function
Description
No.
Definitio
n
Function
Description
1
485A1
-
1
RS485
differential
signal +
Used to cascade
inverters or
connect to the
SmartLogger.
2
485A1
-2
RS485
differential
signal +
Used to cascade
inverters or
connect to the
SmartLogger.
3
485B1
-
1
RS485
differential
signal
–
4
485B1
-2
RS485
differential
signal
–
5
PE
Ground point
on the shield
layer
–
6
PE
Ground
point on the
shield layer
–
7
485A2
RS485
differential
signal +
Connects to the
RS485 signal
port on the
power grid
scheduling
power meter.
8
DIN1
Dry contact
for power
grid
scheduling
–
9
485B2
RS485
differential
signal
–
10
DIN2
11
–
–
–
12
DIN3
13
GND
GND
–
14
DIN4
15
DIN5
Rapid
shutdown/NS
protection/OV
GR
Supports
functions such
as rapid
shutdown, NS
protection, and
OVGR.
16
GND
Installing the Signal Cable
4.6
•
When laying out the signal cable, separate it from the power cable and keep it away from
strong interference sources to avoid strong communication interference.
•
Ensure that the protective layer of the cable is inside the connector, that excess core wires
are cut off from the protection layer, that the exposed core wire is totally inserted into the
cable hole, and that the cable is connected securely.

Huawei SUN2000-50KTL-ZHM3 Specifications

General

Brand	Huawei
Model	SUN2000-50KTL-ZHM3
Category	Inverter
Language	English
