General| Model | SUN2000-M1 |
|---|---|
| Manufacturer | Huawei |
| Max Efficiency | 98.6% |
| Max DC Voltage | 1100 V |
| Number of MPPTs | 2 |
| Rated AC Grid Frequency | 50 Hz / 60 Hz |
| Adjustable Power Factor Range | 0.8 leading to 0.8 lagging |
| Total Harmonic Distortion (THD) | <3% |
| DC Connection | MC4 |
| Cooling | Natural Convection |
| Protection Degree | IP65 |
| Weight | 17 kg |
| MPPT Efficiency | 99.9% |
| Cooling Method | Natural Convection |
| Protection Level | IP65 |
| Max Input Current | 11A |
| Max AC Power | 5.5 kW |
| Rated AC Voltage | 230V |
| AC Voltage Range | 180 V - 276 V |
| Operating Temperature Range | -25°C to 60°C |
| Dimensions | 525 x 470 x 146 mm |
| Maximum Output Power | 5.5 kW |
