Huawei SUN2000 M5 Series - User Manual

Huawei SUN2000 M5 Series

114 pages

To Next Page

To Next Page

Loading...

SUN2000-(12KTL-25KTL)-M5 Series

User Manual

Issue 03

Date 2023-02-15

HUAWEI DIGITAL POWER TECHNOLOGIES CO., LTD.

Table of Contents

Other manuals for Huawei SUN2000 M5 Series

Quick Guide9 pages

Questions and Answers:

J
james77Sep 18, 2025
What causes External fan abnormal on Huawei SUN2000 M5 Inverter?
- S
  Stephen RobertsonSep 18, 2025
  If your Huawei Inverter displays 'External fan abnormal', it could be due to a short-circuited fan, insufficient power, or a blocked air channel. Try the following: 1. Shut down the fan and DC switch, inspect the fan blades for damage, and clear any obstructions around the fan. 2. Reinstall the fan, turn on the DC switch, and wait for the inverter to start. If the alarm persists after 15 minutes, replace the external fan.
J
Joshua RichardsonAug 25, 2025
Why does my Huawei SUN2000 M5 Inverter display Grid Overvoltage?
- W
  whitejonathanAug 25, 2025
  If your Huawei Inverter is showing a 'Grid Overvoltage' alarm, it could be due to the power grid voltage exceeding acceptable limits. Here's what to do: 1. If the alarm is occasional, it might be a temporary grid issue; the inverter should recover automatically. 2. If the problem persists, check if the grid voltage is within the normal range. If it's not, contact your local power operator. If it is, you might need to adjust the grid overvoltage protection threshold using the app, SmartLogger, or NMS, but only with the power operator's consent. 3. If the alarm continues long-term, check the peak voltage of the grid and contact the power operator if needed.
C
christophervaldezAug 25, 2025
Why is my Huawei SUN2000 M5 Inverter showing Grid Undervoltage?
- M
  Marie StephensAug 26, 2025
  If your Huawei Inverter displays a 'Grid Undervoltage' error, it means the power grid voltage is too low. Here’s what to do: 1. If the alarm is occasional, it could be a temporary issue with the power grid, and the inverter should recover automatically. 2. If the alarm persists, verify that the power grid voltage is within the acceptable range. If not, contact your local power operator. If the voltage is within range, you might need to adjust the grid undervoltage protection threshold via the app, SmartLogger, or NMS, but only with the consent of the local power operator. 3. If the alarm continues for a long time, inspect the AC circuit breaker and the AC output power cable.
E
Edward PenningtonAug 27, 2025
Why is my Huawei SUN2000 M5 displaying Grid Overfrequency?
- K
  Kyle ThompsonAug 27, 2025
  If your Huawei Inverter is showing a 'Grid Overfrequency' alarm, it indicates that the power grid frequency is too high. Here’s what to do: 1. If the alarm occurs occasionally, it may be due to a temporary grid abnormality. The inverter should recover automatically when the grid returns to normal. 2. If the alarm persists, check whether the power grid frequency is within the acceptable range. If not, contact the local power operator. If it is within range, consider modifying the grid overfrequency protection threshold through the app, SmartLogger, or NMS, but only with the consent of the local power operator.
P
Peter BowersSep 22, 2025
What does Abnormal Active Power Scheduling Instruction mean on Huawei SUN2000 M5?
- P
  Patrick JensenSep 22, 2025
  If your Huawei Inverter displays 'Abnormal Active Power Scheduling Instruction' or 'Abnormal Reactive Power Scheduling Instruction', it indicates an issue with the DI input or a configuration mismatch. Check that the cables are correctly connected to the DI ports. Then, view the DI signal configuration mapping table on the DI scheduling screen under dry contact settings. Contact the power grid company to verify that the configurations in the mapping table are complete and meet the requirements.
G
glunaSep 23, 2025
What causes Protection upon Communication Failure on Huawei Inverter?
- A
  anthonyruizSep 23, 2025
  If your Huawei Inverter displays 'Protection upon Communication Failure', it means communication was lost for too long, triggering the protection function. Check the communication cable connection. Once communication is restored, the device will recover upon receiving a scheduling command. If this protection isn't needed, you can disable it.
K
Kevin MooreSep 9, 2025
What does Built-in PID operation abnormal mean on Huawei SUN2000 M5 Inverter?
- C
  ccareySep 9, 2025
  If your Huawei Inverter displays 'Built-in PID operation abnormal', it could be due to low output resistance of PV arrays to ground, or low system insulation resistance. For Cause ID = 1, turn off both AC and DC switches, wait, then turn them back on. If the alarm persists, contact support. For Cause ID = 2, check the impedance between the PV array output and ground for shorts or insufficient insulation; rectify if found. If the alarm persists, contact support.
J
Jeffrey JimenezSep 12, 2025
What to do for Device fault on Huawei SUN2000 M5?
- G
  gomezcharlesSep 12, 2025
  If your Huawei Inverter is showing a 'Device Fault' alarm, it indicates an unrecoverable internal circuit fault. Try turning off the AC output switch and DC input switch, wait 5 minutes, then turn them back on. If the alarm persists, contact your dealer or Huawei technical support.
D
Dana YoungSep 3, 2025
How to troubleshoot Abnormal Grounding on Huawei SUN2000 M5 Inverter?
- M
  Michael MartinezSep 3, 2025
  If your Huawei Inverter displays 'Abnormal Grounding', it indicates that the neutral wire or PE cable isn't connected, or the inverter's output mode doesn't match the cable connection. Power off the inverter (AC and DC switches off, wait for specified time). Then: 1. Check the PE cable connection. 2. If connected to a TN grid, check the neutral wire connection and its voltage to ground. 3. After powering on, ensure the inverter's output mode matches the cable connection.
M
Matthew YoungSep 1, 2025
What causes Grid voltage imbalance on Huawei SUN2000 M5?
- A
  Autumn LeonardSep 1, 2025
  If your Huawei Inverter displays a 'Grid voltage imbalance' alarm, it means the difference between the power grid phase voltages is too high. Here's what to do: 1. If the alarm occurs occasionally, it may be due to a temporary grid issue, and the inverter should recover automatically. 2. If the alarm persists, check if the power grid voltage is within the acceptable range. If not, contact the local power operator. 3. If the alarm persists long-term, check the AC output power cable connection. 4. If the cable is correctly connected but the alarm continues, and it's affecting your PV plant's energy yield, contact the local power operator.

Huawei SUN2000 M5 Series Specifications

General

Max Efficiency	98.6%
Max Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Operating Temperature Range	-25°C to +60°C
Communication	RS485, 4G (optional)

Summary

Safety Information

General Safety Statements and Precautions

Provides overarching safety guidelines and disclaimers for handling the equipment.

Personal Safety Guidelines

Details crucial safety measures to protect individuals during operation and maintenance.

Electrical Safety Precautions

Outlines essential safety practices related to electrical connections and operations.

Environment Requirements for Installation

Specifies the environmental conditions necessary for safe and proper inverter operation.

Mechanical Safety and Handling Procedures

Covers safe practices for moving, installing, and handling the inverter and its components.

Installation

Checking Before Installation

Installation Position Requirements

Installing the Inverter

Guides users through the step-by-step process of mounting and installing the inverter.

Electrical Connections

Electrical Connection Precautions

Highlights safety warnings and precautions before making electrical connections.

Preparing Cables for Connection

Connecting the Ground Cable

Installing DC Input Power Cables

Guides users on how to connect the DC input power cables correctly.

Installing AC Output and Signal Cables

Explains the procedures for connecting AC output and signal cables.

Commissioning

Check Before Power-On

Lists critical checks to perform before powering on the system for the first time.

Powering On the System

Details the step-by-step procedure for safely powering on the inverter system.

Man-Machine Interactions

App Commissioning Procedures

Parameter Settings and Control

Maintenance

Powering Off the System Safely

Provides the procedure for safely powering down the inverter before maintenance.

Routine Maintenance Schedule

Troubleshooting Common Issues

Lists common alarms, their possible causes, and troubleshooting steps.

Device Commissioning

Accessing the Commissioning Screen

Guides on how to access the device commissioning screen via the app.

Connecting to the Inverter for Commissioning

Resetting Password

Password Reset Procedure

Locating Insulation Resistance Faults

Fault Identification and Causes

Fault Location Procedure

Rapid Shutdown

Triggering Rapid Shutdown

NS Protection
