Specications Inverter Built-
in WiFi
WLAN-FE Smart
Dongle
4G Smart Dongle
Bandwidth 20 MHz/40 MHz
(optional)
20 MHz/40 MHz
(optional)
LTE features:
● Supports a maximum of 3GPP R8 non-
CA Cat 4 FDD and TDD.
● Supports 1.4 MHz/3 MHz/5 MHz/10
MHz/15 MHz/20 MHz RF bandwidth.
● Supports MIMO in the downlink.
● LTE-FDD: maximum downlink rate of
150 Mbit/s and maximum uplink rate
of 50 Mbit/s
● LTE-TDD: maximum downlink rate of
130 Mbit/s and maximum uplink rate
of 30 Mbit/s
UMTS features:
● Supports 3GPP R7 HSDPA+, HSDPA,
HSUPA, and WCDMA.
● Supports QPSK and 16QAM
modulation.
● HSDPA+: maximum downlink rate of
21 Mbit/s
● HSUPA: maximum uplink rate of 5.76
Mbit/s
● WCDMA: maximum downlink rate of
384 kbit/s and maximum uplink rate
of 384 kbit/s
GSM features:
GPRS:
● Supports GPRS multislot class 12.
● Coding schemes: CS-1, CS-2, CS-3, and
CS-4
● Maximum downlink rate: 85.6 kbit/s;
maximum uplink rate: 85.6 kbit/s
EDGE:
● Supports EDGE multislot class 12.
● Supports GMSK and 8-PSK modulation
and coding schemes.
● Downlink coding format: MCS 1–9
● Uplink coding format: MCS 1–9
● Maximum downlink rate: 236.8 kbit/s;
maximum uplink rate: 236.8 kbit/s
SDongleB-06-EU (WiFi): 20 MHz/40 MHz
(optional)
