SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-

M3

User Manual

Issue 18

Date 2024-03-10

HUAWEI TECHNOLOGIES CO., LTD.

Table of Contents

About this Document3
- Table of Contents8
1 Safety Information11
- Personal Safety12
- Electrical Safety14
- Environment Requirements17
- Mechanical Safety18
2 Overview23
- Product Introduction23
- Appearance26
- Label Description27
- Working Principles29
- Circuit Diagram29
- Working Modes30
3 Inverter Storage32
4 Installation34
- Checking before Installation34
- Tools35
- Determining the Installation Position36
- Moving the Inverter41
- Installing the Mounting Bracket41
- Support Mounting42
- Wall Mounting43
- Installing the Inverter44
5 Electrical Connections47
- Precautions47
- Preparing Cables48
- Connecting the PE Cable51
- Connecting an AC Output Power Cable53
- Connecting DC Input Power Cables58
- Cable Connection Description58
- Connecting Cables to Amphenol Helios H4 Terminals60
- Connecting Cables to Staubli MC4 Terminals61
- Optional) Installing the Smart Dongle63
- Connecting Signal Cables65
- Communication Modes68
- Optional) Connecting the RS485 Communications Cable to the SUN200070
- Optional) Connecting the RS485 Communications Cable to the Power Meter71
- Optional) Connecting the Power Grid Scheduling Signal Cable72
- Optional) Connecting the Rapid Shutdown Signal Cable73
6 Commissioning74
- Checking before Power-On74
- System Power-On75
7 Human-Machine Interaction77
- Scenario in Which Sun2000S Are Connected to the Fusionsolar Smart PV Management System78
- Optional) Registering an Installer Account78
- Creating a PV Plant and a User80
- Smartlogger Networking81
- Scenario in Which Inverters Connect to Other Management Systems81
- Energy Control81
- Grid-Tied Point Control81
- Setting Feed-In at Limited Current85
- Connecting the App to the Inverter or Smart Dongle86
- Scenario Where the App Connects to the Smartlogger87
- Apparent Power Control on the Inverter Output Side88
8 Maintenance90
- System Power-Off90
- Routine Maintenance91
- Alarm Reference92
9 Handling the Inverter93
- Removing the SUN200093
- Packing the SUN200093
- Disposing of the SUN200093
10 Technical Specifications94
A Grid Codes105
B Device Commissioning121
C Built-In PID Recovery124
D Rapid Shutdown125
E NS Protection126
F Resetting a Password127
G Setting Dry Contact Scheduling Parameters128
H Afci129
I PV String Access Detection131
J Smart I-V Curve Diagnosis134
K Locating Insulation Resistance Faults135
L Contact Information139
M Digital Power Customer Service141
N Acronyms and Abbreviations142

Other manuals for Huawei SUN2000-30KTL-M3

Quick Guide20 pages

Questions and Answers:

M
Michelle CurtisSep 23, 2025
How to troubleshoot 'Built-in PID operation abnormal' on Huawei SUN2000-30KTL-M3 Inverter?
- C
  Cameron MartinezSep 23, 2025
  If you encounter a 'Built-in PID operation abnormal' error on your Huawei Inverter: ? If Cause ID = 1: Turn off the AC output switch and DC input switch, wait for a period of time, and then turn on the DC input switch and AC output switch. If the alarm persists, contact your dealer or Huawei technical support. ? If Cause ID = 2: Check the impedance between the PV array output and the ground. If a short circuit occurs or the insulation is insufficient, rectify the fault. If the alarm persists, contact your dealer or Huawei technical support.
G
gsimpsonAug 23, 2025
Why is my Huawei SUN2000-30KTL-M3 Inverter showing 'High string input voltage'?
- N
  Nicholas BlakeAug 25, 2025
  The 'High string input voltage' error on your Huawei Inverter means the PV array isn't configured correctly. There are too many PV modules connected in series, causing the PV string open-circuit voltage to exceed the inverter's maximum operating voltage. To fix this, reduce the number of PV modules connected in series until the PV string open-circuit voltage is at or below the maximum inverter operating voltage. The alarm should then disappear.
C
Charles LeblancAug 25, 2025
What to do if my Huawei SUN2000-30KTL-M3 Inverter displays 'DC arc fault'?
- J
  John CareyAug 26, 2025
  If your Huawei Inverter is showing a 'DC arc fault', it means the PV string power cables are arcing or have poor contact. You should check the PV string cables for arcing or poor connections.
A
Alexander LeeAug 27, 2025
What causes 'String reverse connection' in Huawei SUN2000-30KTL-M3 and how to fix it?
- P
  Pamela SalasAug 27, 2025
  The 'String reverse connection' error in your Huawei Inverter means the PV string polarity is reversed. To resolve this, wait until night when solar irradiance decreases and the PV string current drops below 0.5 A. Then, turn off both DC switches and correct the PV string connection.
J
jeremiah10Aug 27, 2025
Why does my Huawei Inverter show 'Grid overvoltage'?
- P
  parkjesseAug 27, 2025
  A 'Grid overvoltage' alarm on your Huawei Inverter indicates that the power grid voltage exceeds the upper threshold, or the high voltage duration has exceeded the value specified by HVRT. If the alarm is occasional, the power grid may be temporarily abnormal, and the inverter should recover automatically. If the alarm persists, check if the power grid frequency is within the acceptable range, and contact the local power operator if it is not. If the frequency is normal, consider modifying the grid overfrequency protection threshold through the app, SmartLogger, or NMS with the consent of the local power operator. Also, check whether the peak voltage of the power grid is too high, and if the alarm persists long-term, contact the local power operator.
D
Dr. Allison AndersonSep 15, 2025
What does it mean if my Huawei SUN2000-30KTL-M3 Inverter shows a 'Device fault'?
- C
  Christina ParkerSep 15, 2025
  If your Huawei Inverter displays a 'Device fault', it indicates an unrecoverable fault has occurred within the inverter's internal circuitry. To attempt a resolution, turn off the AC output switch and DC input switch, wait 5 minutes, and then turn them back on. If the alarm persists, contact your dealer or Huawei technical support.
R
robertfergusonSep 12, 2025
What does 'Abnormal residual current' mean on Huawei Inverter?
- K
  karenpetersSep 12, 2025
  An 'Abnormal residual current' alarm on your Huawei Inverter indicates that the insulation impedance of the input side to PE decreases when the inverter is operating. If the alarm occurs accidentally, the external power cable may be abnormal temporarily, and the inverter automatically recovers after the fault is rectified. If the alarm persists or lasts a long time, check whether the impedance between the PV string and ground is too low.
S
Sue BernardSep 13, 2025
What to do if Huawei SUN2000-30KTL-M3 Inverter displays 'AFCI self-check failure'?
- B
  browncharlesSep 14, 2025
  To address an 'AFCI self-check failure' on your Huawei Inverter, turn off the AC output switch and DC input switch, and then turn them on again after 5 minutes. If the alarm persists, contact Huawei technical support.
C
Carol LangSep 5, 2025
How to deal with 'Low insulation resistance' error on Huawei SUN2000-30KTL-M3 Inverter?
- B
  boydelizabethSep 5, 2025
  If your Huawei Inverter is showing a 'Low insulation resistance' error, it could be due to: ? The PV array being short-circuited with PE. ? The PV string being in a moist environment for a long time, and the circuit not being well insulated to ground. To address this: ? Check the impedance between the PV string and the PE cable. If a short circuit occurs, rectify the fault. ? Check whether the PE cable of the inverter is correctly connected. ? If you've confirmed that the impedance is lower than the specified protection threshold in a cloudy or rainy environment, log in to the app, SmartLogger, or NMS and set the Insulation resistance protection threshold.
E
Eric GallowaySep 2, 2025
What does 'Grid underfrequency' mean for Huawei Inverter?
- E
  eric08Sep 2, 2025
  A 'Grid underfrequency' alarm on your Huawei Inverter indicates a power grid exception. The actual power grid frequency is lower than the requirements for the local power grid code. If the alarm occurs occasionally, the power grid may be temporarily abnormal. The inverter automatically recovers after detecting that the power grid becomes normal. If the alarm persists, check whether the power grid frequency is within the acceptable range. If not, contact the local power operator. If yes, modify the grid underfrequency protection threshold through the app, SmartLogger, or NMS with the consent of the local power operator.

Huawei SUN2000-30KTL-M3 Specifications

General

Model	SUN2000-30KTL-M3
Max. DC Input Voltage	1100 V
Number of MPPTs	3
Rated AC Output Power	30000 W
Max. Output Current	47.8 A
Frequency	50 Hz / 60 Hz
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	< 3%
Max. Efficiency	98.7%
European Weighted Efficiency	98.4%
DC Connection	MC4
Protection Degree	IP66
Cooling Method	Natural convection
MPPT Voltage Range	200 V - 1000 V
Max. AC Output Power	33000 W
Rated AC Voltage	400 V
AC Voltage Range	320 V - 480 V
Display	LED Indicators
Communication	RS485, WLAN
Operating Temperature Range	-25°C to 60°C
Relative Humidity	0% - 100%
Operating Altitude	4000 m
Weight	43 kg
Dimensions	640 x 530 x 270 mm
Max. DC Input Power	45000 Wp

Summary

Safety Information

Personal Safety Precautions

Covers safety rules for personnel during operations.

Electrical Safety Precautions

Specific safety rules related to electrical connections.

Environment Requirements

Conditions for safe installation and operation environments.

Installation

Determining the Installation Position

Guidelines for selecting the optimal installation site.

Installation Environment Requirements

Specific environmental conditions for installation.

Installing the Mounting Bracket

Steps for attaching the mounting bracket.

Installing the Inverter

Procedures to physically mount the inverter.

Electrical Connections

Precautions

Connecting the PE Cable

Connecting an AC Output Power Cable

Connecting DC Input Power Cables

Commissioning

Checking Before Power-On

System Power-On

Maintenance

System Power-Off

Routine Maintenance

Technical Specifications
