Huawei SUN2000-30KTL-M3 User Manual

5.3 Connecting the PE Cable
D ANGER
● Ensure that the PE cable is securely connected. Otherwise, electric shocks may
occur.
● Do not connect the neutral wire to the enclosure as a PE cable. Otherwise,
electric shocks may occur.
NO TE
● The PE point at the AC output port is used only as a PE equipotential bonding point,
and cannot substitute for the PE point on the enclosure.
● It is recommended that silicone grease or paint be applied around the ground terminal
after the PE cable is connected.
● You can enable or disable phase-to-ground short-circuit protection on the app (choose
Settings > Feature parameters > Phase-to-ground short-circuit protection) to
address the situation in which a phase wire is short-circuited to PE. If this function is
disabled, the inverter detects the alarm and can connect to the power grid and generate
power normally.
Procedure
Step 1 Crimp an OT terminal.
NO TICE
● Avoid scratching the core wire when stripping a cable.
● The cavity formed after the conductor crimp strip of the OT terminal is crimped
must wrap the core wire completely. The core wire must make close contact
with the OT terminal.
● Wrap the wire crimping area with heat shrink tubing or insulation tape. The
heat shrink tubing is used as an example.
● Use a heat gun carefully to avoid heat damage to the equipment.
SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3
User Manual 5 Electrical Connections
Issue 18 (2024-03-10) Copyright © Huawei Technologies Co., Ltd. 41

Huawei SUN2000-30KTL-M3 Specifications

General

Model	SUN2000-30KTL-M3
Max. DC Input Voltage	1100 V
Number of MPPTs	3
Rated AC Output Power	30000 W
Max. Output Current	47.8 A
Frequency	50 Hz / 60 Hz
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	< 3%
Max. Efficiency	98.7%
European Weighted Efficiency	98.4%
DC Connection	MC4
Protection Degree	IP66
Cooling Method	Natural convection
MPPT Voltage Range	200 V - 1000 V
Max. AC Output Power	33000 W
Rated AC Voltage	400 V
AC Voltage Range	320 V - 480 V
Display	LED Indicators
Communication	RS485, WLAN
Operating Temperature Range	-25°C to 60°C
Relative Humidity	0% - 100%
Operating Altitude	4000 m
Weight	43 kg
Dimensions	640 x 530 x 270 mm
Max. DC Input Power	45000 Wp
