Huawei SUN2000-30KTL-M3 - Optional) Installing the Smart Dongle

5.6 (Optional) Installing the Smart Dongle
Procedure
NO TE
The Smart Dongle is not provided in standard conguration.
● 4G Smart Dongle
NO TICE
● If your Smart Dongle is not equipped with a SIM card, prepare a standard
SIM card by yourself (size: 25 mm x 15 mm) with the capacity greater than
or equal to 64 KB.
● When installing the SIM card, determine its installation direction based on
the silk screen and arrow on the card slot.
● Press the SIM card in place to lock it, indicating that the SIM card is
correctly installed.
● When removing the SIM card, push it inward to eject it.
● When reinstalling the enclosure of the Smart Dongle, ensure that the snap-
ts click into place.
Figure 5-15 Installing the 4G Smart Dongle (SDongleA-03)
SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3
User Manual 5 Electrical Connections
Issue 18 (2024-03-10) Copyright © Huawei Technologies Co., Ltd. 53
