7 Human-Machine Interaction

NO TE

● The FusionSolar app is recommended if the inverter connects to the FusionSolar Smart

PV Management System. In areas where the FusionSolar app is unavailable or a third-

party management system is used, only the SUN2000 app can be used for

commissioning.

● Access Huawei AppGallery, search for FusionSolar or SUN2000, and download the app

installation package. You can also scan a QR code below to download the app. You are

advised to use a browser to scan a QR code.

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-

User Manual 7 Human-Machine Interaction
