Huawei SUN2000 Series Quick Installation Guide

9
Main menu
screen
Quick
settings
•
The preset passwords for Common User, Advanced User, and Special User are 00000a.
•
Use the preset password upon initial login. To ensure account security, change the password
immediately after login.
•
The screen snapshots in this document correspond to app 2.2.00.035 (Android).
•
Set the correct grid code based on the application region and scenario of the SUN2000.

Huawei SUN2000 Series Specifications

General

Max Efficiency	98.6%
MPPT Efficiency	99.9%
Protection Rating	IP65
Max. DC Voltage	1100 V
Rated AC Frequency	50 Hz / 60 Hz
Rated Power	3kW - 10kW
Operating Temperature Range	-25 °C ~ +60 °C
Communication	RS485
Rated AC Power	3kW - 10kW
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Total Harmonic Distortion (THD)	≤ 3%
Protection	DC reverse polarity
Cooling	Natural convection
DC Connection	MC4
