4 Cabinet Configurations
Issue 07 (2020-04-10)
Copyright © Huawei Technologies Co., Ltd.
23
4 Cabinet Configurations
4.1 Combined Cabinet
TP482000B-N20B1
Figure 4-1 and Table 4-1 illustrate the TP482000B-N20B1 configurations. Load routes can be
flexibly configured based on site requirements.
Figure 4-1 TP482000B-N20B1 configurations
