Huawei UPS2000-A Series User Manual

UPS2000-A-(6 kVA-10 kVA)
User Manual
2 Overview
Issue 05 (2019-12-19)
Copyright © Huawei Technologies Co., Ltd.
22
Figure 2-7 Rear view of the UPS2000-A-6 kVA/10 kVA professional version with long backup
time
(1) AC input
circuit breaker
(2) Optional card
slot (under the
cover)
(3) EPO port
(4) USB port
a
(security
protection mechanism
supported)
(5) MBS port
(6) Parallel port
(7) Maintenance
bypass circuit
breaker
(8) AC output circuit
breaker
(9) AC input
terminal block
(under the cover)
(10) Jumper terminal
for a single UPS
(under the cover)
(11) AC output
terminal (under the
cover)
(12) Battery wiring
terminal (under the
cover)
a: The USB port supports the standard Modbus protocol and connects to a PC through a USB cable so
that you can access the NMS, configure parameters, export data, and upgrade software.
