Item
Description
MUE07A
DI_1
Corresponds to signal of the input dry contact DI_1 on the MUE07A.
MUE07A
DI_2
Corresponds to signal of the input dry contact DI_2 on the MUE07A.
MUE07A
DI_3
Corresponds to signal of the input dry contact DI_3 on the MUE07A.
MUE07A
DI_4
Corresponds to signal of the input dry contact DI_4 on the MUE07A.
MUE07A
DI_5
Corresponds to signal of the input dry contact DI_5 on the MUE07A.
CIM Parameters
If iBAT is configured, set the parameters in this section by referring to the document delivered
with the iBAT.
Figure 4-55 shows the CIM Param. screen.
Figure 4-55 CIM parameters
On the System Info > Settings > CIM Param. > Basic Param. screen, if Number of battery strings is
0, the Batt. String Config is not displayed on the CIM Param. screen.

Figure 4-56 and Figure 4-57 show the Basic Param. screen.
