HUAWEI Router WS5200
Product Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
1.4 Network Architecture
Figure 1-4 Network architecture
NOTE
Optical fiber (or telephone line/Ethernet cable)
Ethernet cable 2.4 GHz Wi-Fi 5 GHz Wi-Fi
