6 — Control Programming
Scratchpad
Viewing the Scratchpad
The recloser has a convenient scratchpad built in to its non-volatile memory. The memory can store 256 characters of information in text
form. The scratchpad is accessed by selecting the Scratchpad Tab as shown in Figure 6-6. The “Load From Recloser” button will show the
current text stored in the recloser. The text information can be changed in the text box and stored using the “Save To Recloser” button. This
feature could contain any information pertinent to the maintenance and/or tracking of the recloser, such as a source substation name, a
physical address, an install date, or a counter when installed, etc.
Figure 6-8 Scratch pad tab
