11
troublesHootIng
Problem Solution
1.) Rivet pintail is stuck in tool First Step:
Lightly tap nose against a hard surface while after
breaking squeezing HANDLES and pressing down the
RELEASING BUTTON with tool pointing downward Pintail
should then fall out, see g. 4. If that does not work try Second
Step.
Second Step: (Use this only if rst step does not work)
Remove NOSE TUBE and JAW HOLDER (for help see gure 5)
take out pintail and reassemble.
2.) Tool will not reverse Push on the handles until you feel a slight give, then press the
RELEASING BUTTON and continue pushing on the handles,
the tool should then reverse. If this does not work Remove
NOSE TUBE and inspect for any foreign matter that may have
cause the jamming between JAW HOLDER and the inside of
NOSE TUBE.
3.) Fastener does not pull rivet The JAW HOLDER is loose. Remove the NOSE TUBE and
tighten the JAW HOLDER by turning it counterclockwise (see
(See Three Piece Jaw Installation and Removal)).
4.) The rivet does not t into the tool The rivet is to large, or the wrong NOSE PIECE is on the tool.
To nd the correct NOSE PIECE (see chart on page 11). If you
do not have the needed NOSE PIECE, See next page for how
to order the correct one.
5.) Premature breaking See solution for problem 4. Also verify the grip of the fastener
and make sure you are not rocking the tool during installation.
6.) Jamming of tool See solution for problem 4. Also verify that you have the proper
jaw engagement and that all parts are hand tight and that the
jaws are cleaned and properly assembled in jaw pusher (See
Three Piece Jaw Installation and Removal)
7.) Rivet not installed properly See solution for problem 4. Also verify jaw grip and that the
appropriate fastener is being used.
8.) Jaws breaking See solution for problem 4. Check to see all parts are properly
assembled and hand tight.
9.) Damaged jaw pusher See solution for problem 4. Check to see if all parts are properly
assembled.
HK-150 Series Tools (HK1058) Arconic Fastening Systems and Rings
