5
READ INSTRUCTIONS THOROUGHLY PRIOR TO OPERATING THE RIVETER. THIS
RIVETER IS DESIGNED FOR INTERMITTENT DUTY AND MAINTENANCE WORK ONLY.
The HK-150 is a hydraulic tool designed to set from 1/8 inch up to and including 1/4 inch diameter steel, stainless steel,
aluminum and plasc rivets by changing only the nose piece. The HK-150 has a rated pull pressure of over 3,500 lbs and
one handed operaon gives access to ght areas.
The hydraulic system is sealed, oil cannot be added. If the HK-150 should become damaged and leaks oil from the tool, it
should be returned to an authorized service center.
PrIncIPle of oPeratIon
tool sPecIfIcatIons
Operating Temperature Range: 32 ° - 125 ° F ( 0 ° - 51.7 ° C )
Maximum Operating Temperature: 125 ° F ( 51.7 ° C )
STROKE RIVET DIAMETER RIVET MATERIALS PULL PRESSURE WEIGHT
5/8” 1/8”-1/4” Stainless Steel, 3,500 lbs 28 oz
(1.58 cm) (.32-.63 cm) Aluminum, Plastic (15.6 kN) (.79 kg)
HK-150 Series Tools (HK1058) Arconic Fastening Systems and Rings
