Huffy cruiser - Re-attach Front Brake Cable; Brake Adjustment Check Before Riding

11
Assembly
Attach Lower Fender Braces:
1. Line up the Rear Fender Braces
A
with the Frame Mounting Tabs
B
.
2. Insert each lower mounting Bolt
C
into the Frame Mounting Tabs
B
and
tighten securely. Make sure fender is
centered over tire.
Tighten Top Fender Mount:
Note: Top Fender mount is loose to allow
installation.
3. Tighten Bolt
D
and Nut
E
securely.
Make sure fender is centered over tire.
Note: Ensure wheel spins freely without con-
tacting frame or fender.
Rear Fender Assembly
C
B
A
D
E
Re-attach Front Brake Cable (If Equipped):
Re-attach Front Brake Cable:
1. Squeeze the two Brake arms together
A
.
2. Insert the Brake Cable Guide
B
into the
cutout in the Guide Bracket
C
.
3. Make sure the Brake Cable Guide
B
is
seated securely in the Guide Bracket
C
cutout.
WARNING:
Check Front Brake Adjustment Before
Riding!
See Maintenance > Brakes Section
C
A
A
B
B
C
