Installing Pivot Bolt Cover
STEPS:
NOTE: Screws (C) maybe pre-installed in Rear Axle Plate (B). Remove and set
aside.
1. Place Pivot Bolt Cover (A) over Rear Axle Plate (B) so that mounting holes line
up.
2. Install two Screws (C) through Cover and into Rear Axle Plate.
3. Install Screws securely. No not over tighten.
NOTE: Cover must be removed to check Pivot Bolt for tightness.
A
B
C
Assembly
