Connect the adapter with the tab pointing up. The flip
cap on the vehicle’s seven-wire harness will lock
onto the tab (see arrow in the previous graphic) and
help hold the adapter in place. Plug the four-way round
pin connector onto the adapter.
Trailer Recommendations
You must subtract your hitch loads from the Cargo
Weight Rating (CWR). CWR is the maximum weight of
the load your vehicle can carry. It doesn’t include
the weight of the people inside, but you can figure about
150 lbs. (68 kg) for each seat. The total cargo load
must not be more than your vehicles CWR.
Weigh your vehicle with your trailer attached, so that
you won’t go over the GVWR or GAWR. If you are using
a weight-distributing hitch, weigh the vehicle without
the spring bars in place.
You’ll get the best performance if you spread out the
weight of your load the right way, and if you choose the
correct hitch and trailer brakes.
For more information see Towing a Trailer on page 4-63.
4-76
