*1 — Gasoline Engine and Fuel Injection Rail #2.
*2 — Gasoline Engine and Fuel Injection Rail #1.
*3 — Gasoline Engine; Oxygen Sensors.
*4 — Gasoline Engine; Oxygen Sensors.
*5 — Ignition 1
*6 — Powertrain Control Module, Fuel Pump.
*7 — Sunroof.
*8 — Not Used.
Fuses Usage
GLOW PLUG Not Used
CUST FEED Gasoline Accessory Power
HYBRID Not Used
WSW/HTR
Heated Windshield Washer
(Special Edition Only)
STUD #1
Accessory Power/
Trailer Wiring
MBEC 1
Mid Bussed Electrical Center
Power Feed, Front Seats,
Right Doors
BLWR Front Climate Control Fan
Fuses Usage
LBEC 2
Left Bussed Electrical
Center, Door Modules, Door
Locks, Auxiliary Power
Outlet—Rear Cargo Area
and Instrument Panel
STUD #2*
Accessory Power/Trailer
Wiring Brake Feed
ABS Anti-lock Brakes
VSES/ECAS
Electronically Controlled
Air Suspension
IGN A Ignition Switch
IGN B Ignition Switch
LBEC 1
Left Bussed Electrical Center,
Left Doors, Truck Body
Controller, Flasher Module
TRL PARK Parking Lamps Trailer Wiring
RR PARK
Passenger’s Side
Rear Parking and
Sidemarker Lamps
LR PARK
Driver’s Side Rear Parking
and Sidemarker Lamps
PARK LP Parking Lamps Relay
5-121
