Side Imaging®/Sonar Combo View (
1198c SI only)
Side/Sonar Combo View shows sonar information and Side Imaging® sonar information in a
combination split screen, where the Sonar View is displayed on the left and the Side Imaging®
View is displayed on the right.
Select an Active Side, and you can adjust the sensitivity, the side beam range, the chart scrolling
speed, and the color scheme of the display. For more information about each side of this combo
view, see Sonar View and Side Imaging® View.
Side/Sonar Combo View
Side Imaging® Range
9
Boat Icon
10
Bottom Return
11
Tree
12
Shadows
13
Water Column
14
1
2
3 4
Depth
1
Temp: water surface temperature
2
Speed: speed of boat
3
Course: the current direction the boat is traveling measured in degrees from North
4
VLT: Voltage
5
Upper Depth Range
6
Depth Lines
7
5
Lower Depth Range
8
6
8
7
9
9
10
11
13
12
14
