Bottom Range
(Sonar Zoom View only, when Bottom Lock is On)
Settings: 10 - 60 feet, 2-10 fathoms, or 3-20 meters [International
Models only]; Default = 15 feet
Bottom Range allows you to control how much of the water column, measured up from the
bottom, is shown in the Sonar Zoom View. Choose a small value to see low-lying bottom
structure or details of the bottom return. Choose a larger value to see large structure in deeper
water.
NOTE: It is possible to set the Bottom Range to be greater than the depth. In this case, you may see
surface clutter in a wavy band that mirrors changes in the depth.
Cancel Navigation
(only when Navigating)
Settings: Press the RIGHT Cursor key and follow screen instructions.
Cancel Navigation discards the current route and exits Navigation Mode. This menu option will
only appear when you are currently navigating a route. This will not delete a previously-saved
route.
Sonar X-Press™ Menu
140
