121
Chart Menu Tab
Chart Menu Tab
Press the MENU key twice to access the
Main Menu and then press the RIGHT Cursor
key until the Chart tab is selected.
NOTE: Menu options can be expanded or
simplified by setting the User Mode to
Advanced or Normal. See Main Menu: User
Mode for details.
Lat/Lon Grid
Settings: Hidden, Visible, Default = Hidden
Lat/Lon Grid allows you to display or hide a grid showing latitude and
longitude lines.
Navaids on Bird’s Eye View
Settings: Hidden, Visible, Default = Visible
Navaids on Bird's Eye View allows you to display or hide additional
navigational aids in Bird’s Eye View, such as lights and buoys.
NOTE: You will see more navigational aids with an optional-purchase MMC/SD
card.
Chart Select
Settings: Auto, Contour XD, Left Chart Card,
Right Chart Card; Default = Auto
Chart Select allows you to choose which chart to use if you have built-in
charts or a map card. If you select Auto, your unit will select a chart
automatically. Select Right to use the MMC/SD card installed in the right
card slot, and select Left to use the MMC/SD card installed in the left card
slot (see Multi-Media Card (MMC)/SD Slots: Add Maps to Your Fishing
System).
NOTE: The MMC/SD Cards require a separate purchase. For more information,
visit our web site at humminbird.com or contact our Customer Resource Center
at 1-800-633-1468.
NOTE: When a map from an optional
purchase MMC/SD card is installed, the
Chart Menu Tab will change to display
menu options that correspond with the
active chart. To manually select a chart
card, see Chart Select. Also, see Add
Maps to the Fishing System for more
information.
Chart Menu
(shown with optional Navionics®
and LakeMaster® menu options)
