145
Control Head Measurements
HELIX 5 Control Head Measurements
2.90 in (73.66 mm)
3.30 in (83.82 mm)
VIEW
MENU
EXIT
MARK
7.55 in (191.77 mm)
4.28 in
(108.71 mm)
4.64 in
(117.86 mm)
GOTO
MOB
Gimbal Mount (HELIX 5)

Table of Contents

Other manuals for Humminbird HELIX 5 SERIES

Preview: Installation Guide
Installation Guide4 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Humminbird HELIX 5 SERIES and is the answer not in the manual?

Humminbird HELIX 5 SERIES Specifications

General IconGeneral
Tracks50
Waterproof RatingIPX7
Display Size5 inches
GPSYes
Frequency200/455 kHz
Power Output500 watts (RMS)
Max Depth1500 ft (DualBeam PLUS), 350 ft (Down Imaging)
