7-6. Usingthelargewireconnectors,connectthefanandreceiverto
the power wires as follows:
•Connectthewhitewire(A/CIN)fromthereceivertothewhite
wire from the ceiling.
•Connecttheblackwirefromthereceivertotheblackwirefrom
the ceiling.
CAUTION:Besurenobarewireorwirestrandsarevisibleafter
making connections.
7-7. Runthethinwhiteantennawirefromthereceiverthroughone
oftheslotsintheceilingplate.(Forbestreception,makesurethe
end of the antenna is exposed at the top of the canopy.)
7-8. Connectthegreengroundwiresfromtheceilingplateandthe
downrod to the ground wire from the ceiling.
7-9. Pushallwiresandwireconnectorsbackthroughtheceilingplate
holeintotheoutletbox.Placethegreenandwhitewiresona
separatesideoftheoutletboxfromtheotherwires.
