3 • Assembling tbe Blades
Step 3-1
Step 3-2
Holes
Fan Motor
3-1.Insertbladeintoslot.Aligntheholesonthebladewiththeholes
in the fan motor.
3-2.Slideatwashersontotheshaftsofthebladeassemblyscrews.
3-3. Attachthebladetothemotorusingthebladeassemblyscrews.
3-4.Repeatforeachblade.
BladeAssembly
Screw
Flat Washer
