Hunter 42700 - Wiring the Fan

10
42700-01•01/15/08•HunterFanCompany
7 • Wiring the Fan
All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
qualified electrician.
Wallswitchesarenotincluded.Selectanacceptablegeneral-useswitch
in accordance with national and local electrical codes.
7-1. Disconnectthepowerbyturningothecircuitbreakerstothe
outletboxandassociatedwallswitchlocation.
7-2. Placethereceiverinsidethecanopy,makingsurethatthe
dipswitchesandtheovalshapedholesinthebottomofthe
receiverarefacingdowntowardthebottomofthecanopy.
7-3. Spreadthereceiverleadwirestoeachsideandfeedthewiresfrom
thetopofthefanthroughtheopenslotinthereceiver.
7-4. Placethereceiverinthecanopy.Makesuretheslotinthereceiver
is aligned with the hook in the ceiling plate.
7-5. Toconnectthewires,holdthebaremetalleadstogetherand
placeawireconnectoroverthem,thentwistclockwiseuntiltight.
Usingthesmallwireconnectors,connectthefantothereceiveras
follows:
•Connecttheyellowwirefromthefantotheyellowwirefrom
thereceiver.
•Connectthepinkwirefromthefantothepinkwirefromthe
receiver.
•Connectthegreywirefromthefantothegreywirefromthe
receiver.
•Connecttheredwirefromthefantotheredwirefromthe
receiver.
•Connecttheblackwirewithawhitestripefromthefantothe
blackwirewithawhitestripefromthereceiver.
•Connectthewhitewirefromthefantothewhitewire
(LIGHTOUT)fromthereceiver.
Steps 7-5 – 7-6
Large Wire
connector
Small Wire
connector
