MD511-01 • 05/20/14 • © Hunter Fan Company
Make sure the upper switch housing is securely
attached to the mounting plate. Failure to properly
secure all 3 assembly screws could result in the switch
housing xture falling.
Switch Housing
Feed the wire plug through the center
hole of the upper switch housing, then
wrap keyhole slots around the screws and
twist counterclockwise.
Align the screw holes in the switch
housing gasket and the motor housing.
Screw two switch housing assembly
screws from the hardware bag halfway
into the motor housing. It does not matter
which two screw holes you choose.
Insert the third screw, found in
the hardware bag, into place and then
tighten all three screws.
