MD511-01 • 05/20/14 • © Hunter Fan Company
Light Kit (continued)
Make sure the lower switch housing is securely attached to
the upper switch housing. Failure to properly secure all three
assembly screws could result in the light xture falling.
Lift the lower switch housing up until its
screw holes are aligned with the screw holes
in the upper switch housing.
Install the three switch housing screws
found in the hardware bag.
Screw
Holes
Connect the plugs from the upper and lower
switch housings. Make sure to line up the
colored markings on the connectors.
To Next Page
